At TechDaal, we offer innovative systems for steel structure construction, including: houses, multi-purpose halls, offices, commercial spaces, modular buildings, photovoltaic panel structures and solar carports. Each system is designed to provide energy efficiency, structural safety and quick assembly. The galvanized steel and modern technologies used guarantee long-term durability and superior resistance to external factors, such as earthquakes and weather.
Economical exterior wall v1
1. Decorative plaster (other finishes)
2. Expanded polystyrene EPS 70
3. osb3 board or 12.5 mm exterior boards
4. Glass mineral wool (minimum 40kg/m3)
5. 10 or 15 cm profile with 1.5 mm thickness
6. 4 cm air gap (cable space)
7. Aluminized anti-condensation foil with reflection
8. 1.25 cm drywall
9. Plaster, washable or wallpaper
Economical exterior wall v2
1. Decorative plaster (other finishes)
2. Expanded polystyrene EPS 70
3. OSB3 board or 12.5 mm exterior boards
4. Cellulose (minimum 40kg/m3)
5. 10-15 cm profile with a thickness of 1.5 mm
6. Aluminized anti-condensation foil with reflection
7. 1.25 cm drywall
8. Plaster, washable or wallpaper
Standard exterior wall v1
1. Decorative plaster (other finishes)
2. 10 cm EPS 80 expanded polystyrene
3. osb3 board or 12.5 mm exterior boards
4. Rock wool (minimum 40kg/m3)
5. 10 or 15 cm profile with 1.5 mm thickness
6. 4 cm air gap (cable space)
7. Aluminized anti-condensation foil with reflection
8. Two layers of 12.5 mm drywall
9. Plaster, washable or wallpaper
Standard exterior wall v2
1. Decorative plaster (other finishes)
2. 10 cm EPS 80 expanded polystyrene
3. osb3 board or 12.5 mm exterior boards
4. Closed or open cell polyurethane foam (minimum 30kg/m3)
5. 10 or 15 cm profile with 1.5 mm thickness
6. 4 cm air gap (cable space)
7. Aluminized anti-condensation foil with reflection
8. Two layers of 12.5 mm drywall
9. Plaster, washable or wallpaper
Standard exterior wall v3
1. Decorative plaster (other finishes)
2. 10 cm EPS 80 expanded polystyrene
3. OSB3 board or 12.5 mm exterior boards
4. Cellulose (minimum 40kg/m3)
5. 10 or 15 cm profile with 1.5 mm thickness
6. Aluminized anti-condensation foil with reflection
7. Two layers of 12.5 mm drywall
8. Plaster, washable or wallpaper
Standard exterior wall v4
1. Decorative plaster (other finishes)
2. 15 cm EPS 80 expanded polystyrene
3. osb3 board or 12.5 mm exterior boards
4. Cellulose (minimum 40kg/m3)
5. 10 or 15 cm profile with 1.5 mm thickness
6. Two layers of 12.5 mm drywall
7. Aluminized anti-condensation foil with reflection
8. Plaster, washable or wallpaper
Standard exterior wall v5
1. Decorative plaster (other finishes)
2. 10 cm EPS 80 expanded polystyrene
3. osb3 board or 12.5 mm exterior boards
4. Closed or open cell polyurethane foam (minimum 30kg/m3)
5. 10 or 15 cm profile with 1.5 mm thickness
6. 4 cm air gap (cable space)
7. Two layers of 12.5 mm drywall
8. Aluminized anti-condensation foil with reflection
9. Plaster, washable or wallpaper
Standard exterior wall v6
1. Decorative plaster (other finishes)
2. 15 cm EPS 80 expanded polystyrene
3. osb3 board or 12.5 mm exterior boards
4. Closed or open cell polyurethane foam (minimum 30kg/m3)
5. 10 or 15 cm profile with 1.5 mm thickness
6. 4 cm air gap (cable space)
7. Two layers of 12.5 mm drywall
8. Aluminized anti-condensation foil with reflection
9. Plaster, washable or wallpaper
Standard exterior wall v7
1. Decorative plaster (other finishes)
2. 10 cm EPS 80 polystyrene (or basalt wool)
3. osb3 board or 12.5 mm exterior boards
4. 15 cm basalt wool with a density of 40 kg/m?
5. 10 or 15 cm profile with 1.5 mm thickness
6. 1.25 cm vidiwall board (fermacell)
7. UW, CW 50 profile with minimum thickness of 0.5 mm
8. 4 cm air gap (cable space)
9. Two layers of 1.25 cm drywall
10. Aluminized anti-condensation foil with reflection
11. Plaster - washable or wallpaper
12. 15 cm profile with 1.5 mm thickness
Standard exterior wall v8
1. Decorative plaster (other finishes)
2. 15 cm EPS 80 polystyrene (or basalt wool)
3. OSB3 board or 12.5 mm exterior boards
4. 15 cm basalt wool with a density of 40 kg/m3
5. 10 or 15 cm profile with 1.5 mm thickness
6. 1.25 cm vidiwall board (fermacell)
7. UW, CW 50 profile with minimum thickness of 0.5 mm
8. 4 cm air gap (cable space)
9. Two layers of 1.25 cm drywall
10. Aluminized anti-condensation foil with reflection
11. Plaster - washable or wallpaper
12. 15 cm profile with 1.5 mm thickness
Standard exterior wall v9
1. Decorative plaster (other finishes)
2. 10 cm expanded polystyrene
3. osb3 board or 12.5 mm exterior boards
4. 10 cm/m3 glass mineral wool
5. 10 or 15 cm profile with 1.5 mm thickness
6. 4 cm air gap (cable space)
7. Aluminized anti-condensation foil with reflection
8. Two layers of 1.25 cm drywall
9. Plaster, washable or wallpaper
10. 15 cm profile with 1.5 mm thickness
Premium exterior wall v1
1. Decorative plaster (other finishes)
2. 15 cm EPS 80 expanded polystyrene
3. OSB3 board or 12.5 mm exterior boards
4. Rock wool (minimum 40kg/m3)
5. 10 or 15 cm profile with 1.5 mm thickness
6. 4 cm air gap (cable space)
7. Aluminized anti-condensation foil with reflection
8. Two layers of 12.5 mm drywall
9. Plaster, washable or wallpaper
Premium exterior wall v2
1. Decorative plaster (other finishes)
2. 15 cm EPS 80 expanded polystyrene
3. osb3 board or 12.5 mm exterior boards
4. Closed or open cell polyurethane foam (minimum 30kg/m3)
5. 10 or 15 cm profile with 1.5 mm thickness
6. 4 cm air gap (cable space)
7. Aluminized anti-condensation foil with reflection
8. Two layers of 12.5 mm drywall
9. Plaster, washable or wallpaper
Premium exterior wall v3
1. Decorative plaster (other finishes)
2. 15 cm EPS 80 expanded polystyrene
3. osb3 board or 12.5 mm exterior boards
4. Cellulose (minimum 40kg/m3)
5. 10 or 15 cm profile with 1.5 mm thickness
6. Aluminized anti-condensation foil with reflection
7. Two layers of 12.5 mm drywall
8. Plaster, washable or wallpaper
Premium exterior wall v4
1. Decorative plaster (other finishes)
2. 15 cm graphited polystyrene
3. OSB3 board or 12.5 mm exterior boards
4. Cellulose (minimum 40kg/m3)
5. 10-15 cm profile with a thickness of 1.5 mm
6. Aluminized anti-condensation foil with reflection
7. Two layers of 12.5 mm drywall
8. Plaster, washable or wallpaper
Premium exterior wall v5
1. Decorative plaster (other finishes)
2. 15 cm graphited polystyrene
3. OSB3 board or 12.5 mm exterior boards
4. Closed or open cell polyurethane foam (minimum 30kg/m3)
5. 10 or 15 cm profile with 1.5 mm thickness
6. 4 cm air gap
7. Aluminized anti-condensation foil with reflection
8. Two layers of 12.5 mm drywall
9. Plaster, washable or wallpaper
Premium exterior wall v6
1. Decorative plaster (other finishes)
2. 15 cm graphited polystyrene
3. OSB3 board or 12.5 mm exterior boards
4. Rock wool (minimum 40kg/m3)
5. 10 or 15 cm profile with 1.5 mm thickness
6. 4 cm air gap (cable space)
7. Aluminized anti-condensation foil with reflection
8. Two layers of 12.5 mm drywall
9. Plaster, washable or wallpaper
Premium exterior wall v7
1. Decorative plaster (other finishes)
2. 15 cm graphited polystyrene
3. osb3 board or 12.5 mm exterior boards
4. Cellulose (minimum 40kg/m3)
5. 10 or 15 cm profile with 1.5 mm thickness
6. Two layers of 12.5 mm drywall
7. Aluminized anti-condensation foil with reflection
8. Plaster, washable or wallpaper
Premium exterior wall v8
1. Decorative plaster (other finishes)
2. 15 cm graphited polystyrene
3. OSB3 board or 12.5 mm exterior boards
4. Closed or open cell polyurethane foam (minimum 30kg/m3)
5. 10-15 cm profile with a thickness of 1.5 mm
6. 4 cm air gap (cable space)
7. Two layers of 12.5 mm drywall
8. Aluminized anti-condensation foil with reflection
9. Plaster, washable or wallpaper
Premium exterior wall v9
1. Decorative plaster (other finishes)
2. 15 cm graphited polystyrene
3. OSB3 board or 12.5 mm exterior boards
4. Rock wool (minimum 40kg/m3)
5. 10-15 cm profile with a thickness of 1.5 mm
6. 4 cm air gap (cable space)
7. Two layers of 12.5 mm drywall
8. Aluminized anti-condensation foil with reflection
9. Plaster, washable or wallpaper
Exterior wall detail Standard
1. Plaster, washable or wallpaper
2. Two layers of 1.25 cm drywall
3. Aluminized anti-condensation foil with reflection
4. U-profile
5. 10 or 15 cm C-profile
6. Structure fixing anchor
7. 10 cm basalt wool with a density of at least 40 kg/m2
8. OSB3 board or 1.25 cm exterior boards
9. 10 cm EPS 80 polystyrene (or basalt wool)
10. Decorative plaster
11. Bituminous membrane
12. Polystyrene starting profile
13. Concrete stirrup
14. Concrete
15. Expansion membrane
16. Underfloor heating pipes
17. Extruded polystyrene 5 cm base
18. Cement screed 5-6 cm
19. 4 cm air gap (cable space)
Exterior walls
Detail of load-bearing wall connection with floor
1. Floor finish
2. Underfloor heating
3. 5 cm cement screed
4. 5 cm extruded polystyrene
5. Panel fixing screw
6. Profile 20 cm
7. Profile 10 or 15 cm
8. UD profile
9. CD Profile
10. Metal clamp
11. Air gap
12. Corrugated sheet metal with a thickness of 0.8 mm
13. 10 cm basalt wool with a density of at least 40 kg /m³
14. A layer of 1.25 cm drywall
15. Two layers of 1.25 cm drywall
16. Plaster, washable or wallpaper
Detail 1. exterior wall with interior wall
1. Glet, lavabil sau tapet
2. Două straturi gips carton 1,25 cm
3. Gol de aer de 4 cm (loc cabluri)
4. Vată bazalticã de 10 cm cu densitate de minim 40 kg/m³
5. Gol de aer de 4 cm (loc cabluri)
6. 10 cm or 15 cm C-profile
7. 6.3 mm screws
8. Aluminized anti-condensation foil with reflection
9. Two layers of 1.25 cm drywall
10. Plaster, washable or wallpaper
Detail 2. exterior wall with interior wall
1. Decorative plaster
2. 10 cm EPS 80 polystyrene
3. OSB3 board or 1.25 cm exterior boards
4. 10 cm basalt wool with a density of at least 40 kg/mª
5. 4 cm air gap (cable space)
6. 10 or 15 cm C-profile
7. 15 cm C-profile
8. 6.3 mm screws
9. Aluminized anti-condensation foil with reflection
10. Two layers of 1.25 cm drywall
11. Plaster, washable or wallpaper
Interior wall corner detail
1. Plaster, washable or wallpaper
2. Two layers of 1.25 cm drywall
3. 10 cm basalt wool with a density of at least 40 kg/m3
4. 4 cm air gap (cable space)
5. 10 cm or 15 cm C-profile
6. 4 cm air gap (cable space)
7. Aluminized anti-condensation foil with reflection
8. Two layers of 12.5 mm drywall
9. Plaster, washable or wallpaper
Exterior corner detail
1. Decorative plaster
2. 10 cm EPS 80 polystyrene (or basalt wool)
3. OSB3 board or 1.25 cm exterior boards
4. 10 cm basalt wool with a density of at least 40 kg/m3
5. 4 cm air gap (cable space)
6. 10cm or 15cm C-profile
7. Aluminized anti-condensation foil with reflection
8. Two layers of 1.25 cm drywall
9. Plaster, washable or wallpaper
Intermediate floor
1. Floor finish
2. Underfloor heating
3. Cement screed
4. Extruded polystyrene
5. 0.8 mm thick corrugated sheet
6. 9 cm air gap (cable space)
7. C-profile 15cm - 20cm
8. Mineral wool
9. 3 cm air gap
10. CD Profile
11. Metal clamp
12. A layer of 1.25 cm drywall
Interior wall, floor and intersection details
Glass door lintel detail
1. Decorative plaster
2. 10 cm EPS 80 polystyrene (or rock wool)
3. 5 cm extruded polystyrene
4. 2 cm extruded polystyrene
5. 1.25 cm OSB board or exterior boards
6. 10 cm basalt wool with a density of at least 40 kg/m?
7. Two layers of 1.25 cm drywall
8. Aluminized anti-condensation foil with reflection
9. Plaster, washable or wallpaper
10. C-profile 10 cm
11. C-profile 15 cm
12. Polyurethane foam for carpentry installation
13. Exterior carpentry half-frame
14. Glass window
15. Exterior window sill
16. Interior window sill
17. Proper sealing
Detail of Standard exterior windows and doors
1. Decorative plaster
2. 10 cm EPS 80 polystyrene (or basalt wool)
3. OSB3 board or 1.25 cm exterior boards
4. 10 cm basalt wool with a density of at least 40 kg/m°
5. 15 cm C profile (material 5-350 Z275)
6. 5 cm air gap (cable space)
7. Aluminized anti-condensation foil with reflection
8. Two layers of 1.25 cm drywall
9. Plaster, washable or wallpaper
10. 5 cm extruded polystyrene
11. 2 cm extruded polystyrene
12. Window frame
13. Glass window
Standard exterior door detail
1. Decorative plaster
2. 10 cm EPS 80 polystyrene (graphitized polystyrene, basalt wool)
3. OSB board or 1.25 cm exterior boards
4. 10 cm basalt wool with a density of at least 40 kg/m°
5. 4 cm air gap (cable space)
6. Two layers of 1.25 cm drywall
7. Aluminized anti-condensation foil with reflection
8. Plaster, washable or wallpaper
9. C-profile 15 cm
10. Extruded polystyrene 2 cm
11. Extruded polystyrene 5 cm
12. Exterior carpentry half frame
13. Exterior joinery glass
14. Floor finish
15. Semi-dry screed 5-6 cm
16. Underfloor heating system
17. Concrete stirrup
18. Reinforced concrete
19. Polyethylene foil
20. Gravel for breaking capillarity
21. Compacted soil
22. Polyurethane foam for carpentry installation
Exterior door detail with balcony/terrace
1. Plaster, washable or wallpaper
2. A layer of 1.25 cm drywall
3. Aluminized anti-condensation foil with reflection
4. 4 cm air gap (cable space)
5. 10 cm basalt wool with a density of at least 40 kg/m°
6. OSB board or 1.25 cm exterior boards
7. 10 cm EPS 80 polystyrene (graphitized polystyrene, basalt wool)
8. Decorative plaster
9. C-profile 150 mm
10. Extruded polystyrene 5 cm
11. Extruded polystyrene 2 cm
12. Polyurethane foam for carpentry installation
13. Exterior joinery glass
14. Floor finish
15. Semi-dry screed 5-6 cm
16. Underfloor heating system
17. Corrugated sheet with a thickness of 0.8 cm
18. UD profile
19. Exterior carpentry half-frame according to manufacturer's specification
20. Waterproofing
21. Exterior finishes (tiles)
22. Railing attached to C profile
23. Neoprene for thermal bridge prevention
Detail top view of door glass
1. Decorative plaster
2. 10 cm EPS 80 polystyrene (or rock wool)
3. 5 cm extruded polystyrene
4. 2 cm extruded polystyrene
5. 1.25 cm OSB board or exterior boards
6. 10 cm basalt wool with a density of at least 40 kg/m?
7. 4 cm air gap
8. Two layers of 1.25 cm drywall
9. Aluminized anti-condensation foil with reflection
10. Plaster, washable or wallpaper
11. C-profile 150 mm
12. Polyurethane foam for carpentry installation
13. Exterior carpentry half frame
14. Glass window
Window / door / lintel details
Ventilated facade detail v1
1. Exterior finish - aluminum bond, painted sheet metal or tiles
2. Dowels
3. Mounting system provided by the manufacturer
4. Rock wool
5. OSB3 board or 1.25 cm exterior boards
6. C-profile
7. Aluminized anti-condensation foil with reflection
8. Two layers of 1.25 cm drywall
Ventilated facade detail v2
1. Exterior finish - exposed brick, PVC paneling, wood
2. Dowels
3. Mounting system provided by the manufacturer
4. Polystyrene
5. OSB3 board or 1.25 cm exterior boards
6. Rock wool
7. C-profile
8. Aluminized anti-condensation foil with reflection
9. Two layers of 1.25 cm drywall
Ventilated facade details
Standard Attic
1. Attic closing sheet
2. Chalkboard apron
3. Panel fixing screw
4. Extruded polystyrene 5 cm base
5. OSB3 board or 1.25 cm exterior boards
6. 4 cm air gap (cable space)
7. C-type profile
8. 10 cm basalt wool with a density of at least 40 kg/m3
9. 10 cm EPS 80 polystyrene (or basalt wool)
10. Decorative plaster
11. Isopanel or sandwich panel
Standard attic closure
1. Corrugated sheet metal
2. Air gap
3. Profile
4. Panel fixing screw
5. Extruded polystyrene 5 cm
6. OSB3 board or 1.25 cm exterior boards
7. 4 cm air gap (cable space)
8. 10 cm basalt wool with a density of at least 40 kg/m3
9. 10 cm EPS 80 polystyrene (or basalt wool)
10. C-type profile
11. Decorative plaster
12. Attic closing board
13. Chalkboard apron
Standard Attic
1. Roof covering
2. Wooden slat
3. Anti-condensation foil
4. OSB3 board or 1.25 cm exterior boards
5. Profile
6. Joint element
7. 10 cm basalt wool with a density of at least 40 kg/m3
8. Profile
9. C-profile plasterboard - metal bracket
10. Air gap
11. Aluminized anti-condensation foil with reflection
12. Two layers of 1.25 cm drywall
13. Plaster, washable or wallpaper
14. Polystyrene eps 80 of 10 cm
15. Putty knife
16. Decorative plaster
17. Profile according to architecture
18. Wood paneling or decorative plaster
19. Gutter
Standard exterior framing
1. 15 cm C-profile with 1.5 mm thickness (material 5-350 Z275)
2. OSB3 board or 1.25 cm exterior boards
3. 10 cm EPS 80 polystyrene (or basalt wool)
4. Wood paneling or decorative plaster with polystyrene
5. Decorative plaster
6. Anti-condensation foil
7. Wooden slat
8. Roof covering
9. Insulation
10. Profile
11.Gutter
Roof systems
CONTACT
Request a personalized offer
